perma ULTRA installation kits are highly versatile and can be adapted for attachment to beam sections, square mesh safety cages or rail mount. The brackets included in perma ULTRA installation kits are fabricated in Australia from stainless steel.
perma ULTRA installation kits are available in multiple hose lengths - 1.0, 1.5, 2.0, 3.0, 4.0, 5.0, 10 and 15 mtrs.
The perma ULTRA must be remote mounted, providing the opportunity to install the system at a safe and easy to access location. Installation kits include pre-assembled hose and a range of easy to use attachment options. Installation kit part numbers include the length of the pre-assembled hose in meters. Care should be taken to order kits with suitable hose lengths because in-field adjustments is not practical
beam mount installation kits
Part No. KU165-1M-90HP-06
1 point Beam clamp installation kit
1 point perma ULTRA bracket
2 x 65mm beam clamp
1 x full length heavy duty cover
1 x 1/4" BSP M nipple SS
2 x 1/4" BSP M to 9/16" JIC M nipple
1 x T-piece with grease nipple
1.0 mtr pre-assembled high pressure hose 9/16" JIC F swivel
1 x Elbow 90° 9/16" JIC M to 1/4" BSP M SS
1 x Reducer 1/4" BSP F to 1/8" BSP M SS
Part No. KU165-5M-90HP-06
1 point Beam clamp installation kit
1 point perma ULTRA bracket
2 x 65mm beam clamp
1 x full length heavy duty cover
1 x 1/4" BSP M nipple SS
2 x 1/4" BSP M to 9/16" JIC M nipple
1 x T-piece with grease nipple
5.0 mtr pre-assembled high pressure hose 9/16" JIC F swivel
1 x Elbow 90° 9/16" JIC M to 1/4" BSP M SS
1 x Reducer 1/4" BSP F to 1/8" BSP M SS
Part No. KU165-10M-90HP-06
1 point Beam clamp installation kit
1 point perma ULTRA bracket
2 x 65mm beam clamp
1 x full length heavy duty cover
1 x 1/4" BSP M nipple SS
2 x 1/4" BSP M to 9/16" JIC M nipple
1 x T-piece with grease nipple
10 mtr pre-assembled high pressure hose 9/16" JIC F swivel
1 x Elbow 90° 9/16" JIC M to 1/4" BSP M SS
1 x Reducer 1/4" BSP F to 1/8" BSP M SS
Cage hanger installation kits
Part No. KU1CH-1M-90HP-06
1 point Cage hanger installation kit
1 point perma ULTRA bracket
1 X Cage hook arm set
1 x full length heavy duty cover
1 x 1/4" BSP M nipple SS
2 x 1/4" BSP M to 9/16" JIC M nipple
1 x T-piece with grease nipple
1.0 mtr pre-assembled high pressure hose 9/16" JIC F swivel
1 x Elbow 90° 9/16" JIC M to 1/4" BSP M SS
1 x Reducer 1/4" BSP F to 1/8" BSP M SS
Part No. KU1CH-5M-90HP-06
1 point Cage hanger installation kit
1 point perma ULTRA bracket
1 X Cage hook arm set
1 x full length heavy duty cover
1 x 1/4" BSP M nipple SS
2 x 1/4" BSP M to 9/16" JIC M nipple
1 x T-piece with grease nipple
5.0 mtr pre-assembled high pressure hose 9/16" JIC F swivel
1 x Elbow 90° 9/16" JIC M to 1/4" BSP M SS
1 x Reducer 1/4" BSP F to 1/8" BSP M SS
Part No. KU1CH-10M-90HP-06
1 point Cage hanger installation kit
1 point perma ULTRA bracket
1 X Cage hook arm set
1 x full length heavy duty cover
1 x 1/4" BSP M nipple SS
2 x 1/4" BSP M to 9/16" JIC M nipple
1 x T-piece with grease nipple
10 mtr pre-assembled high pressure hose 9/16" JIC F swivel
1 x Elbow 90° 9/16" JIC M to 1/4" BSP M SS
1 x Reducer 1/4" BSP F to 1/8" BSP M SS
Rail mount installation kits
Part No. KU1RR-1M-90HP-06
1 point Rail mount installation kit
1 point perma ULTRA bracket
2 x U-bolts
1 x full length heavy duty cover
1 x 1/4" BSP M nipple SS
2 x 1/4" BSP M to 9/16" JIC M nipple
1 x T-piece with grease nipple
1.0 mtr pre-assembled high pressure hose 9/16" JIC F swivel
1 x Elbow 90° 9/16" JIC M to 1/4" BSP M SS
1 x Reducer 1/4" BSP F to 1/8" BSP M SS
Part No. KU1RR-5M-90HP-06
1 point Rail mount installation kit
1 point perma ULTRA bracket
2 x U-bolts
1 x full length heavy duty cover
1 x 1/4" BSP M nipple SS
2 x 1/4" BSP M to 9/16" JIC M nipple
1 x T-piece with grease nipple
5.0 mtr pre-assembled high pressure hose 9/16" JIC F swivel
1 x Elbow 90° 9/16" JIC M to 1/4" BSP M SS
1 x Reducer 1/4" BSP F to 1/8" BSP M SS
Part No. KU1RR-10M-90HP-06
1 point Rail mount installation kit
1 point perma ULTRA bracket
2 x U-bolts
1 x full length heavy duty cover
1 x 1/4" BSP M nipple SS
2 x 1/4" BSP M to 9/16" JIC M nipple
1 x T-piece with grease nipple
10 mtr pre-assembled high pressure hose 9/16" JIC F swivel
1 x Elbow 90° 9/16" JIC M to 1/4" BSP M SS
1 x Reducer 1/4" BSP F to 1/8" BSP M SS
